The Fujikura CT50 is a high-precision optical fiber cleaver that handles single fibers and up to 16-fiber ribbon in both single-mode and multimode. Its motorized blade delivers roughly 60,000 cleaves before replacement, and a Bluetooth link lets a paired 90S+ splicer rotate the blade automatically when wear is detected. The compact, battery-powered body makes it well suited to field FTTx and splicing work.

Key features

• Cleaves single fiber and up to 16-fiber ribbon, single-mode or multimode
• Low cleave angles: avg. 0.3-0.9° single fiber, 0.3-1.2° ribbon
• Motorized blade rotation (also a manual dial) with approx. 60,000 cleaves per blade
• Bluetooth 4.1 LE link enables automatic blade rotation when paired with a Fujikura 90S+ splicer
• Compact and light (approx. 306 g) with AAA-battery power for field use
• Replaceable blade and clamp arm; fiber-scrap collector for off-cut management

Specifications

• Model: CT50
• Fiber type: Single-mode and multimode
• Fiber count: Single fiber up to 16-fiber ribbon
• Cladding diameter: Approx. 125 μm
• Applicable coating: AD-10-M24: max 900 μm; AD-50: max 3 mm
• Cleave length: 5-20 mm (AD-10-M24); fiber holder approx. 10 mm
• Cleave angle: Single fiber avg. 0.3-0.9°; ribbon avg. 0.3-1.2°
• Blade life: Approx. 60,000 fiber cleaves
• Blade rotation: Motorized and manual dial
• Battery: 2 x LR03 (AAA) dry batteries
• Wireless: Bluetooth 4.1 LE
• Tripod mount: 1/4-20 UNC screw hole
• Dimensions (W x D x H): Approx. 117 x 94 x 59 mm (without projection)
• Weight: Approx. 306 g (incl. battery and AD-10-M24)
• Operating temperature: -10°C to +50°C (storage -40°C to +80°C)
• Humidity: 0 to 95% RH non-condensing
• Replaceable parts: Blade (CB-08), clamp arm (ARM-CT50-01)

Applications

• Optical fiber cleaving for fusion splicing in FTTx, access and datacom networks
• Field and workshop single-fiber and ribbon-fiber preparation
