The BlueStorm DS-Gel is a 12 V digital-screen intelligent gel storage battery from the Gel Energy Storage Deep Cycle series. It is a maintenance-free gel (VRLA) design carrying a built-in digital screen that shows real-time battery status and is built for repeated deep-discharge cycling in solar and energy-storage systems. The datasheet covers three 12 V capacities that share the same charging, temperature, and storage behaviour and differ mainly in capacity, size, and weight.

Key features

• The built-in digital screen shows real-time battery status.
• Maintenance-free gel (VRLA) electrolyte, deep-cycle rated
• Solar / energy-storage deep-cycle design for repeated discharge
• Capacity range of 100 / 150 / 210 Ah at the 10-hour rate (12 V)
• Low self-discharge: 65% residual capacity after 12 months storage (25°C)
• Certified to UL, CE, ISO 9001, ISO 14001 and OHSAS 18001

Specifications

• Nominal voltage: 12 V · 12 V · 12 V
• Capacity, 10 h rate (25°C): 100 Ah (10 A) · 150 Ah (15 A) · 210 Ah (20 A)
• Capacity, 3 h rate: 82 Ah · 117 Ah · 180 Ah
• Capacity, 1 h rate: 63 Ah · 86 Ah · 128 Ah
• Internal resistance (full charge, 25°C): 5 mΩ · 4 mΩ · 3.2 mΩ
• Max. initial charging current: < 30 A · < 45 A · < 60 A
• Cycle-use charge voltage (25°C): 14.5-14.9 V · 14.5-14.9 V · 14.5-14.9 V
• Float charge voltage (25°C): 13.6-13.8 V · 13.6-13.8 V · 13.6-13.8 V
• Dimensions L×W×H, ±2 mm: 333 × 173 × 216 mm · 484 × 170 × 241 mm · 522 × 239 × 217 mm
• Weight (approx.): 31.5 kg · 44.7 kg · 63.7 kg
• Container colour: Grey · Grey · Grey

Shared across all three capacities: constant-voltage charge 2.30 V/cell at 0.20 CA; residual capacity 91% / 82% / 65% after 3 / 6 / 12 months storage (25°C); capacity vs. temperature 100% at 25°C, 104% at 40°C, 83% at 0°C and 65% at -15°C (from 50% at -20°C up to 105% at 45°C).

Applications

• Solar photovoltaic energy-storage systems
• Off-grid and backup power / energy storage
• Deep-cycle duty requiring repeated discharge and recharge
