The BlueStorm Mini OTDR (model BS-0T-SCUPC) is a compact handheld optical tester that combines five fiber tools in one instrument: an OTDR, an optical power meter (OPM), a visual fault locator (VFL), a stabilized light source (LS) and an RJ45 network-cable test, with an Event Map view for reading OTDR traces. It operates at 1310/1550 nm with 24/22 dB dynamic range and a maximum test range of 80 km, and is driven through a 4.3-inch capacitive touch screen (800×480) behind a tempered-glass panel. A 5200 mAh lithium battery, sink-type optical ports and multiple export interfaces make it suited to field fiber installation and maintenance.

Key features

• 5-in-1 fiber tester: OTDR, optical power meter, visual fault locator, light source and network-cable test
• 1310/1550 nm OTDR with 24/22 dB dynamic range and up to 80 km test range
• Short dead zones: event < 2.0 m, attenuation < 7.0 m; minimum 0.2 m sampling resolution
• 4.3-inch capacitive multi-touch screen (800×480) with tempered-glass cover; horizontal or vertical operation
• 5200 mAh lithium battery with >10 h standby; U-disk, SD card and Micro-USB data export
• SC/UPC optical interface (per model BS-0T-SCUPC)

Specifications

• Model: BS-0T-SCUPC
• Wavelengths: 1310 / 1550 nm
• Dynamic range: 24 dB (1310 nm) / 22 dB (1550 nm)
• Max. test range: 80 km
• Measuring ranges: 100 m, 500 m, 2 / 5 / 10 / 20 / 40 / 80 km (90 km)
• Sampling resolution: Minimum 0.2 m
• Event dead zone: < 2.0 m
• Attenuation dead zone: < 7.0 m
• Sampling points: 64,000
• Linearity: ≤ 0.05 dB/dB
• Loss threshold: 0.01 dB
• Loss resolution: 0.001 dB
• Range resolution: 0.01 m
• Range accuracy: ±(0.5 m + range × 3×10⁻⁵ + sampling resolution), excluding refractive-index error
• Memory: > 40,000 records
• Optical power meter (OPM): Type A: +10 to -70 dBm; Type B: +26 to -50 dBm
• Visual fault locator (VFL): 10 mW, CW / 2 Hz
• Light source (LS): Output -5 dBm; CW / 270 Hz / 1 kHz / 2 kHz
• Network-cable test: Wire-sequence testing and wire alignment
• Display: 4.3-inch TFT-LCD capacitive touch, 800×480
• Data interface: 2× USB (Type-A ×1, Micro-USB ×1) + SD card
• Battery: 3.7 V / 5200 mAh lithium
• Operating temperature: -10 to +55°C
• Storage temperature: -20 to +80°C
• Humidity: ≤ 95% (non-condensing)
• Size / weight: 175 × 105 × 45 mm / 0.56 kg (incl. battery)

Applications

• Fiber-optic link installation, acceptance testing and characterization
• Fault location, break finding and loss/event analysis on fiber
• Optical power and insertion-loss measurement (OPM + light source)
• RJ45 network-cable wire-map verification

In the box

Standard accessories: FC adaptor, power adapter, lithium battery, USB cable, quick guide and portable carry package.
