The BlueStorm BS-WMC6-G-12U is a 12U wall-mounted network/server cabinet built from powder-coated SPCC steel with a 5 mm tempered-glass front door. It measures 600 mm wide x 600 mm deep x 640 mm high and ships with a fan, PDU, shelf and copper earthing cable. A 450 mm-deep version (BS-WMC4-G-12U) is also offered, and custom sizes can be produced.

Key features

• 12U usable rack capacity in a compact wall-mount footprint.
• Powder-coated 1.2 mm SPCC steel body with a 5 mm tempered-glass front door.
• Supplied with a fan, PDU, shelf and copper earthing cable.
• Ventilated (perforated) side panels and a top-mounted fan for airflow.
• Quick-open latches, side lock and stainless-steel cage nuts for secure, easy assembly.
• Available in 600 mm or 450 mm depth; custom sizes on request.

Specifications

• Model: BS-WMC6-G-12U (600 mm depth); BS-WMC4-G-12U (450 mm depth)
• Type: Wall-mounted cabinet
• Rack capacity: 12U
• Width: 600 mm
• Depth: 600 mm (450 mm option)
• Height: 640 mm
• Frame material: 1.2 mm SPCC steel, powder-coated
• Front door: 5 mm tempered glass + 1.2 mm SPCC steel
• Side / top / bottom: 1.2 mm SPCC steel, powder-coated
• Mounting profile: 1.5 mm SPCC steel, powder-coated
• Hinges: 2.0 mm steel
• Cage nuts: 30 x stainless steel
• Door lock: Hold lock (side lock optional)
• Packing: Disassembled, 2 cartons

In the box

• 12U wall-mounted cabinet
• Fan x 1
• PDU x 1
• Shelf x 1
• Copper earthing cable x 1
• Cage nuts x 30
